Fiio's recent unveiling of the KB3 HiFi Audio Mechanical Keyboard marks a significant step in the fusion of high-fidelity audio technology with mechanical keyboard craftsmanship. Engineered to serve as a comprehensive desktop audio solution, the KB3 integrates dual CS43131 DACs and SGM8262 op-amps, delivering a robust 550mW of output power, rivalling traditional desktop amplifiers. This allows for an exceptional audio experience, with support for high-resolution audio formats up to 32bit/384kHz and DSD256.

In terms of its keyboard functionality, the KB3 boasts a gasket mount design, which effectively absorbs shocks and reduces noise, making it suitable for both quiet work environments and engaging gaming sessions. It employs Gateron G Pro 3.0 yellow switches, known for their reliability and suitability for diverse typing and gaming needs. The keyboard's structure, crafted from an aluminum-magnesium alloy, offers a premium feel and durability.

Designed to accommodate both Mac and Windows users, the KB3 provides flexibility for a wide range of users. One of its standout features is a stepless volume knob, allowing users to finely tune their audio experience without having to toggle between software settings.

User reactions to the KB3 have been varied, with some expressing excitement about its potential to save desk space while offering a dual-purpose device. Others are intrigued by the combination of audiophile-grade audio with a high-performance keyboard, though there are reservations regarding its build quality, noise levels, and keyboard layout compatibility.

Overall, the Fiio KB3 represents a novel approach in the tech industry, seeking to cater to the needs of audiophiles and keyboard enthusiasts alike. Its unique combination of features positions it as a versatile and innovative product in the market.
















Fiio KB3: Where Hi-Fi Audio Meets Mechanical Precision

Discover the Fiio KB3 - A groundbreaking keyboard combining superb Hi-Fi audio and mechanical prowess. Perfect for audiophiles and gamers alike.


When it comes to iconic designs in the world of audio equipment, few can match the allure and appeal of the Brionvega RR126 Radiophonograph. Designed by Italian masters Achille and Pier Giacomo Castiglioni in 1965, the RR126 is more than just a functional piece of audio equipment—it's an art form. In this article, we'll delve into the features, design, and legacy of this remarkable machine.

## Aesthetics and Design

Encased in a sleek wooden box, the Brionvega RR126 features a turntable, radio, and speakers, all beautifully integrated into a modular form factor. The setup is designed to adapt to your space and lifestyle. The speaker units, for instance, can be detached from the main console and placed elsewhere, allowing for greater flexibility in sound optimization.

## Functionality

This unit is far more than just a pretty face. It comes with a built-in FM/AM radio tuner, a high-fidelity turntable, and audio inputs for external sources. While the technology may seem dated in the era of digital audio, the RR126 has an analog warmth and richness that is often lacking in modern devices.

## Collectibility and Availability

Owing to its rarity and the nostalgia it evokes, the Brionvega RR126 has become a collector's item, often appearing in European HiFi auctions. Prices for a unit in good condition can range from a few thousand to tens of thousands of dollars depending on its provenance and condition.

## Interior Design Appeal

Because of its iconic aesthetic, the RR126 doesn't merely serve as a functional piece of audio equipment; it's also a striking piece of interior design. Whether you choose to place it in a minimalist modern home or a vintage-styled apartment, the RR126 is sure to capture attention and spark conversation.

## Technical Specifications

-   **Turntable**: 33, 45, and 78 RPM with automatic or manual arm movement
-   **Radio**: FM and AM bands
-   **Speakers**: Detachable, allowing flexibility in positioning
-   **Inputs**: Various inputs including RCA for additional audio sources

## Conclusion

The Brionvega RR126 Radiophonograph represents an intersection of art, design, and audio technology. As a collector's item, its value goes beyond mere function, encapsulating an era and a style that continues to be appreciated by audiophiles and design enthusiasts alike. It's not just an appliance; it's a piece of history.





Brionvega RR126 Radiophonograph: A Piece of Audiophile History

The Brionvega RR126 Radiophonograph is a 1965 iconic masterpiece combining art, design, and audio technology. This collector's item features a high-fidelity turntable, FM/AM radio, and detachable speakers, encapsulating the golden era of analog sound while serving as a striking piece of interior design.

#### Why Acoustic Terminology Matters

Understanding the language of acoustics is not just for scientists or sound engineers; it's essential for anyone passionate about achieving the best sound experience, whether you're an audiophile or a professional. Knowing terms like "Reverberation" or "Absorption" can help you diagnose problems in your listening room or even enhance your enjoyment of music or movies.

#### The Four Pillars

At the heart of acoustic understanding are four key terms: Reverberation, Absorption, Reflection, and Diffusion. Think of these as the four pillars that uphold the 'temple' of sound quality. Understanding these terms can significantly elevate your listening experience.

----------

### Unpacking Reverberation

#### What is Reverberation?

Reverberation is the continuation of sound in a particular space even after the original sound source has stopped. Imagine clapping your hands in an empty room; the sound lingers for a few moments, bouncing off the walls, ceiling, and floor. That lingering is reverberation. Too much of it can muddy sound quality, while too little can make a room feel "dead."

#### Reverberation Time (RT60)

RT60 is a metric that measures how long it takes for the sound to decay by 60 decibels in a room. In simple terms, it gauges how 'echoey' a room is. Measuring RT60 helps in tuning a room for optimal sound quality. For example, a home theater might aim for a shorter RT60 to keep dialogues crisp, while a concert hall might aim for a longer RT60 to enrich musical notes.

#### The Role of Reverberation in Different Environments

Reverberation behaves differently depending on where you are. In a recording studio, excessive reverberation is usually undesirable as it can muddle the clarity of recordings. Conversely, in a concert hall, a certain level of reverberation can add richness and warmth to live performances. Even in your living room, getting the reverberation right can make your hi-fi system shine.

----------

### The Absorption Factor

#### What is Sound Absorption?

Sound absorption refers to the process where materials, like acoustic foam or carpeting, "soak up" sound waves, reducing echo and background noise. Imagine sound absorption like a sponge soaking up water, but in this case, the sponge is soaking up sound energy.

#### Noise Reduction Coefficient (NRC)

The Noise Reduction Coefficient (NRC) is a number between 0 and 1 that indicates how well a material absorbs sound. A higher NRC means better absorption. For example, acoustic ceiling tiles with an NRC of 0.7 would absorb 70% of the sound hitting them, reflecting the remaining 30% back into the room.

#### Practical Applications of Absorption

In a home theater, strategic placement of absorbing materials can help reduce unwanted noise and echoes, making dialogues and musical scores clearer. In recording studios, absorption is essential for capturing the 'true' sound of an instrument or voice without interference from the room itself. Even in industrial settings, absorption can be crucial for employee comfort and safety, mitigating the impact of machine noise.

----------

### Understanding Reflection

#### The Basics of Sound Reflection

Sound reflection is the phenomenon where sound waves bounce off surfaces like walls, floors, and ceilings. Imagine throwing a ball at a wall; it comes back to you, right? Sound behaves similarly. When sound waves encounter a hard surface, they reflect back into the room. This can either be a positive or negative factor, depending on what you're aiming for acoustically.

#### First Reflection Points

First reflection points are the initial surfaces that sound waves hit after leaving a speaker. They're critical because these first reflections will reach the listener almost immediately after the direct sound, and can either clarify or muddy the sonic picture. In most cases, these are spots on your side walls, ceiling, or floor. Knowing where these points are can help you decide where to place absorbing or diffusive materials.

#### Reflective Surfaces and Sound Quality

Reflective surfaces aren't all bad; sometimes they're exactly what a room needs. For example, in a home theater, you might want some reflection off the side walls to make the audio sound more spacious. However, in a recording studio, excessive reflection could distort the true sound of an instrument or voice. The key is to find a balance between reflective and absorbent surfaces.

----------

### The Complexity of Diffusion

#### What is Sound Diffusion?

Diffusion is the scattering of sound waves in multiple directions. Unlike absorption or reflection, which deal with sound in a more linear way, diffusion disperses sound, reducing the sense of localization. Think of it like a garden sprinkler for sound; it scatters water (sound) uniformly in different directions.

#### Types of Diffusers

There are various types of diffusers, but two common ones are Quadratic Residue Diffusers (QRD) and Primitive Root Diffusers (PRD). QRDs use a sequence of well depths to scatter sound, while PRDs utilize a different mathematical formula for a more randomized scattering. Both have their strengths and weaknesses, but the goal is the same: to spread sound energy across a room evenly.

#### The Role of Diffusion in Room Acoustics

Diffusion can enhance a space by making it sound larger and more open. It helps break up sound energy and redistributes it throughout the room. This is beneficial in places like home theaters where you want a balanced, immersive sound field, or in music studios where you want to capture a more natural ambiance.

----------

### Putting it All Together

#### The Interplay Between the Four Terms

Understanding Reverberation, Absorption, Reflection, and Diffusion in isolation is good, but appreciating how they interact is even better. For instance, too much absorption can make a room sound lifeless, but adding diffusion can breathe life back into it. Likewise, too much reflection could cause problems, but the right amount of reverberation could fix it.

#### Case Studies

Real-world examples can illustrate how a blend of these four elements can create an acoustically optimized space. Whether it's a Grammy-winning recording studio or a state-of-the-art home theater, the principles remain the same: balance and harmony between these four pillars.

#### Final Thoughts and Further Resources

Mastering these terms is essential for anyone interested in acoustics, whether you're a professional or just passionate about sound. For those looking to deepen their knowledge, various books, online courses, and consultation services are available to guide you further.

Photo of a modern HiFi listening room.png

What is Reverberation, Absorption, Reflection, and Diffusion

A proper understanding of acoustical terminology is essential for effective room treatment. Learn how they impact room treatment and sound quality.


## Introduction to Acoustic Metrics

### Why Acoustic Metrics Matter

Sound is more than just what we hear; it's a wave that behaves in specific ways in different environments. To better understand and control how sound behaves in a space—be it a home theater, recording studio, or an open-office layout—we use acoustic metrics. These metrics provide us with a quantitative means of assessing and improving a room's acoustical properties.

### Brief Overview of NRC and STC

Noise Reduction Coefficient (NRC) and Sound Transmission Class (STC) are two of the most commonly used acoustic metrics. NRC tells us how well a material absorbs sound, thereby reducing echo and reverberation. STC, on the other hand, measures how effectively a material can block sound from traveling from one space to another. Both metrics are crucial for anyone interested in acoustics, from audiophiles to architects.

----------

## Exploring NRC (Noise Reduction Coefficient)

### What is NRC?

NRC, or Noise Reduction Coefficient, is a number between 0 and 1 that represents the fraction of sound energy absorbed by a material. A score close to 1 indicates that the material is very effective at absorbing sound, while a score near 0 means it reflects most of the sound hitting it.

### How to Interpret NRC Ratings

NRC ratings are often found on products like acoustic panels, carpets, and ceiling tiles. A material with an NRC rating of 0.75, for example, would absorb 75% of sound energy and reflect the remaining 25%. In spaces where clear, detailed sound is essential—such as recording studios or home theaters—an NRC rating closer to 1 is generally desired.

### Practical Applications of NRC

Understanding NRC is essential when you are looking to control sound within a space. In recording studios, materials with high NRC ratings are used to reduce ambient noise and improve recording quality. In home theaters, NRC-rated panels can significantly enhance the viewer's experience by cutting down on distracting echoes and reverberations. Even in noisy industrial settings, NRC can play a role in creating a more acoustically pleasant environment.

----------

## The Importance of STC (Sound Transmission Class)

### What is STC?

Sound Transmission Class (STC) is a metric that measures a material's ability to block sound from traveling through it. Unlike NRC, which focuses on absorption within a single space, STC helps us understand how soundproof a material is between two distinct spaces.

### Factors Affecting STC Ratings

Several factors can affect a material's STC rating, including its density, thickness, and how it's installed. Generally, materials like concrete and brick have high STC ratings, making them excellent for soundproofing. However, even a high-STC material can underperform if it's installed poorly, such as with gaps or cracks that allow sound to seep through.

### STC in Real-world Scenarios

In residential buildings, understanding STC can help you create a quieter and more private living environment by choosing walls, floors, and doors with higher STC ratings. In commercial settings, like offices or hospitals, STC-rated partitions can greatly enhance privacy and reduce noise pollution.

----------

## NRC vs STC - Knowing When to Use Which

### Different Goals, Different Metrics

While both NRC and STC are instrumental in shaping a room's acoustic properties, they serve different purposes. NRC is used for improving sound quality within a room by minimizing echo and reverberation. STC is used for isolating rooms from each other, ensuring that sound doesn't leak from one space to another. Knowing which metric to focus on is crucial for effective acoustic treatment.

### Complementary but Not Interchangeable

It's important to note that a material with a high NRC rating won't necessarily have a high STC rating, and vice versa. For example, foam panels may have excellent sound absorption properties but may not be effective in soundproofing between rooms.

### Case Examples

-   **Home Theater**: You'd likely be concerned with both NRC (to improve sound quality within the room) and STC (to prevent sound leakage into other parts of the home).
-   **Recording Studio**: NRC would be critical here to capture clean recordings, but STC would also be important to ensure external noises don't contaminate the recording.

----------

## Measuring and Evaluating Acoustic Metrics

### Tools of the Trade

Sound level meters, room analysis software, and specialized microphones can be used to measure and analyze acoustic metrics. These tools can provide a quantitative evaluation that can guide you in choosing the right materials.

### DIY vs Professional Analysis

Simple mobile apps can give you a basic understanding of a room's acoustics, but for critical applications like studios or professional theaters, you may need to consult with acoustics professionals for a more detailed evaluation.

### Understanding the Numbers

-   **NRC**: Generally, an NRC rating of 0.6 or higher is considered good for most indoor environments.
-   **STC**: An STC rating of 50 or higher is considered excellent for blocking out most everyday noises.

----------

## Practical Applications and Recommendations

### Tailoring to Your Needs

Your specific needs will dictate whether you should prioritize NRC, STC, or both. Are you trying to improve the acoustics of an open office, or are you more concerned with soundproofing an in-home cinema?

### Material Selection

-   For high NRC: Look for specialized acoustic panels, fabrics, and foams.
-   For high STC: Consider denser materials like mass-loaded vinyl, drywall, or even specialized acoustic doors.

### When to Consult an Expert

If you're dealing with complex acoustic challenges or need specialized solutions, it might be wise to consult an acoustics professional for a more in-depth analysis and tailored solutions.

simple sound insulating panel with a neutral-colored fabric finish.png

Introducing Acoustic Metrics: NRC , STC

Explore the essential acoustic metrics NRC and STC, learn their differences and applications, and discover how to measure and optimize them for better sound quality and isolation.
