Features

Eco Mode:

  • Eco mode availability

Power Selection:

  • Adaptable to alternative power tubes

Bias Control:

  • Display and setting of quiescent current

Protection System:

  • Soft start
  • Protection circuit for amplifier and power tubes

Inputs:

  • 1 x RCA + 1 x XLR (switchable)

Output Power at 4 Ohms:

  • High: 200 W (RMS)
  • Low: 140 W (RMS)

Frequency Response:

  • 20 Hz - 70 kHz / -3 dB at full power

Input Resistance:

  • 50 kOhm RCA
  • 25 kOhm XLR

Signal-to-Noise Ratio:

  • -116 dB (100 µV 150 Hz - 15 kHz)

Amplification:

  • +26 dB RCA

Input Sensitivity:

  • 1 V RCA
  • 2 x 0.5 V XLR

Damping Factor:

  • Switchable, DF Low = 4, DF High = 8 (8 ohms load)
