PMC
MB2 XBD
About
The 3 way MB2 XBD series is flexible in the extreme, its many variants allowing it to fill roles from high-power midfield to large-scale soffit-mounted main monitoring. Higher SPLs with lower distortion and greater dynamic capacity are key features, but all units include a usable frequency range fro...
Related Content
No related content yet
Features
## Available Finishes
- Walnut
- Cherry
- Oak
- Black Ash
## Crossover Frequency
- 380Hz
## Dimensions
- Height: 1740mm / 68.50"
- Width: 380mm / 14.96"
- Depth: 535mm / 21.06"
## Drive Units
- Low Frequency: 2 x 310mm Radial™
- Mid Frequency: 75mm PMC fabric dome
- High Frequency: 34mm PMC soft dome
## Effective ATL™ Length
- 3m / 10ft
## Weight
- 88kg / 193.6lbs per channel
## Amplifier Power per Channel
- High Frequency: 120W
- Mid Frequency: 120W
- Low Frequency: 600W
