This setup is a cozy corner for anyone who loves the warm crackle of a vinyl record and the rich sounds of jazz. It's a mix of old and new, with pieces like the Sansui 9090 receiver and Luxman MQ60 tube amplifier bringing out the best in classic records. These pieces are known for making music feel full and alive, which is perfect for getting lost in the grooves of a good jazz album. The turntable, a Denon DP-57L with its special Denon 103D pickup, is ready to spin any record, from the newest pressings to old favorites, making sure every note is clear and vibrant.

The setup also has a nod to the days of mixtapes with a Technics cassette deck, ready for when you feel like a retro vibe. And when it's time for something more modern, there's a Pioneer CD player that keeps digital tunes sounding great. Everything comes together through Klipsch speakers that make sure every song fills the room without missing a beat. It's a space that's built for sinking into the music, whether that's a lively jazz tune or any song that means something special.

by: jazz_and_vinyl


The Warmth of Vinyl and Jazz

The Sansui 9090 and 990 are vintage receivers that were produced in the 1970s, recognized for their robust build quality and exceptional audio performance. Both models are part of the Sansui's 90 series, featuring significant power amplification through their impressive output stages. The Sansui 9090 has an output power of 120 Watts per channel, while the 990 model boasts an even more powerful 130 Watts per channel. These receivers include multiple inputs for connecting various audio sources, such as turntables, tape decks, and CD players. They often feature tuning dials with analog displays, offering a classic aesthetic alongside high-quality sound reproduction. The units typically incorporate a range of sound adjustment controls, including bass, treble, and balance. In terms of connection options, both models generally feature speaker terminals allowing for various speaker configurations, making them versatile in different audio setups. Additionally, their FM and AM radio capabilities include a sensitive tuner for better reception and sound clarity.

9090/990

The Luxman MQ-60 is a vacuum tube power amplifier that exemplifies the craftsmanship and engineering excellence associated with Luxman products. This amplifier is designed to drive a variety of speakers while delivering a warm, rich sound signature typical of tube amplification. The MQ-60 employs 6L6GC output tubes and is configured in a push-pull design, allowing it to achieve both high fidelity and dynamic range. It features a robust power supply section that ensures stable operation even under load. The amplifier produces a power output of approximately 30 watts per channel, which is adequate for driving medium to high efficiency speakers. Its frequency response typically ranges from 20 Hz to 20 kHz, maintaining a solid performance across the audible spectrum. The MQ-60 is praised for its intricate design, which includes a beautifully laid-out chassis and high-quality components, reflecting the brand's commitment to audio excellence. The amplifier comes with various input options, allowing for versatile connectivity. Overall, the Luxman MQ-60 is highly regarded for its sound quality, aesthetic appeal, and reliable performance.

MQ-60

The Technics RS-630 USD is a cassette deck introduced by Technics.

RS-630 USD

The Denon DP-57L is a direct-drive turntable that features a sleek and stylish design, reflecting the aesthetics of the late 1970s and early 1980s. It is engineered for optimal playback performance and aims to reproduce audio with authenticity and clarity. The turntable is equipped with a high-torque direct-drive motor, which ensures consistent speed and stability. The unique construction of the DP-57L includes a heavy, damped chassis that helps minimize vibrations and unwanted resonance during playback. This model also features an S-shaped tonearm, designed to reduce tracking error and optimize record contact. Additionally, it has an adjustable tracking force and anti-skate control to further enhance playback accuracy. The DP-57L is compatible with a range of cartridges, allowing users to customize their audio experience based on personal preferences. The unit's build quality is robust, aimed at durability and longevity, making it a solid choice for vinyl enthusiasts.

DP-57 L

The Denon DL-103 D is a moving coil (MC) phono cartridge made by Denon. It is known for its exceptional sound quality and has been highly regarded by audiophiles and enthusiasts. The DL-103 D features a low output voltage and requires a phono preamp or step-up transformer with sufficient gain. It has a diamond stylus for accurate tracking and a rugged construction for durability. The DL-103 D is designed to be used with a high-quality turntable setup and is often considered a benchmark in the world of audiophile cartridges.

DL-103 D

The Pioneer PD-S 701 is a compact disc player manufactured by Pioneer from 1992 to 1993 in Japan. It features a sleek design available in black and champagne colors. The player is equipped with remote control functionality and has a power consumption of 16 watts. Its dimensions are 420 mm in width, 276 mm in height, and 130 mm in depth, with a weight of 4.2 kg. The PD-S 701 offers both variable and fixed audio outputs. It utilizes a 1-bit transducer and provides an impressive frequency response range from 2 Hz to 2 kHz, with a dynamic range exceeding 96 dB and a signal-to-noise ratio greater than 108 dB. The distortion factor is minimal at less than 0.0026%. While it does not support CD-Text, MP3 playback, or pitch control, it includes features such as auto play, shuffle, title programming, and repeat modes. The player is compatible with CD-R, CD-RW, and HDCD formats.

PD-S 701

The PHO-701 is an enhanced version of the successful PHO-700 tube phono preamplifier, offering significant improvements in customization and sound quality. Unlike its predecessor, the PHO-701 includes DIP-switches, allowing users to make precise adjustments tailored to their specific pick-up cartridge needs. This feature eliminates the need for compromises typically required in many other phono preamplifiers. Consequently, users experience a notable enhancement in sound quality and fine resolution, achieving a richer and more detailed audio reproduction.

PHO-701

The Klipsch Forte III is a floor-standing loudspeaker that continues the legacy of the Forte series with modern enhancements aimed at delivering superior audio performance. The speaker features a 12-inch woofer, a 6.5-inch midrange driver, and a 1-inch titanium compression driver coupled with a Tractrix horn for high frequencies. The combination of these drivers produces a seamless and dynamic sound across a broad range of frequencies. The Forte III offers a sensitivity rating of approximately 99 dB, allowing it to produce high sound pressure levels with relatively low input power. It also features a frequency response that ranges from 38 Hz to 20 kHz, providing deep bass and crisp treble sound. The crossover network is designed to ensure smooth transitions between the drivers, and the cabinet is constructed from high-quality wood veneers, enhancing both aesthetics and acoustics. The speakers are compatible with different amplifier types, making them versatile for various audio setups. Along with these acoustic features, the Forte III benefits from a solid build quality, ensuring durability and longevity. It is also equipped with dual binding posts, allowing for bi-wiring or bi-amping configurations, enhancing its performance capabilities. Overall, the Forte III maintains Klipsch's commitment to high-efficiency sound reproduction, making it a compelling choice for audiophiles and music enthusiasts alike.

Forte III

The setup is a curated showcase of the Sony ES series, known for its detailed sound reproduction, displayed with an evident appreciation for design and auditory experience. Each component, from the turntable to the amplifiers, is deliberately placed, creating an environment that’s both acoustically and visually harmonious. The ambient lighting from the neon sign adds a touch of warmth, enhancing the vintage charm of the space. The overall arrangement is inviting, with comfortable seating poised for immersive listening, all resting on patterned rugs that contribute to the room’s acoustic texture. This setup is not just about the specs; it's a stage that celebrates the art of listening, resonating with a narrative that’s as rich as the music it's designed to play.

by: stereo_sony_es







The Audiophile's Vintage Modern Blend

The Sony TA-E 2000 ESD is a versatile preamplifier and processor that was manufactured from 1993 to 1998 in Japan. It features an array of advanced audio processing options, including DSP (Digital Signal Processing) for three distinct digital effects functions, and three separate 3-band digital parametric equalizers dedicated to front, center, and rear channels. The device includes a Digital Dynamic Compressor and Expander, along with 10 pre-programmed room simulations that can be customized through 10 memory slots. Volume adjustments can be controlled via an included remote. The integrated A/D and D/A converter supports high-quality audio conversion using a 1 Bit High Density Linear Converter System, and it offers a frequency response of 10 Hz to 20 kHz with minimal distortion (less than 0.004%). It supports Dolby ProLogic Surround and features a 5.1 output configuration. Connectivity options are extensive, including six A/V inputs, three A/V outputs, and various digital and analogue inputs/outputs, accommodating both modern and traditional audio equipment. The unit is designed in a sleek black finish, complementing its high-end audio capabilities.

TA-E 2000 ESD

The Sony CDP-C 79 ES is a CD player with a 5-disc capacity. It was released in the mid-1990s and is known for its high-quality sound output and durable build. It also features a variety of playback options and settings for customization.

CDP-C 79 ES

The Sony CDP-CA80ES is a 5-disc CD changer that offers a blend of solid build quality, good sound reproduction, and a variety of features catering to music enthusiasts. It features a heavy aluminum panel that lends a premium feel, despite being a multi-disc player. Users have praised its excellent sound clarity and impressive soundstage, allowing for detailed listening experiences where subtle musical elements are easily discernible. The unit includes features like programming, shuffling, and a disc naming capability, although the effectiveness of automatic disc titling has been noted to rely on limited CD compatibility. While it is positioned below audiophile standards, many users appreciate its performance relative to its price point; often considered a better value compared to other changers. It has RCA analog and optical digital outputs, but lacks a digital coaxial out, which some enthusiasts might find limiting. The player is compatible with various audio setups and integrates well with other Sony equipment. Overall, it's considered an excellent choice for those wanting an accessible multi-disc player without compromising on sound quality.

CDP-CA80ES

The Sony TA-F 808 ES is an integrated amplifier produced between 1993 and 1994, showcasing a robust design and high-quality audio performance. This model is crafted in Japan and features a sleek aesthetic available in black or champagne finishes. The amplifier includes a remote control (RM-S 703) for convenient operation. It has a power consumption rating of 390 W and dimensions of 470 x 175 x 435 mm, weighing in at 24.6 kg. At launch, it was priced at 2,500 DM for the black version and 2,600 DM for the champagne version.

In terms of connectivity, the TA-F 808 ES provides a total of six line inputs, one direct input, and one phono input suitable for MM and MC cartridges (with 40 Ohm and 3 Ohm load options). It also includes an adaptor in/out which can serve as an additional high-level input. The amplifier supports multiple output options including one pre-out, one adaptor out, and connections for two pairs of loudspeakers (A+B).

The technical specifications reveal continuous power output of 120 W per channel at 8 Ohms and 170 W at 4 Ohms (RMS 20Hz - 20kHz). When measured at 1 kHz, the DIN power output increases to 135 W and 200 W at 8 and 4 Ohms respectively. The amplifier exhibits low total harmonic distortion, rated at 0.004%, and a high signal-to-noise ratio of 105 dB for line inputs. Frequency response ranges from 2 Hz to 200 kHz, ensuring a wide bandwidth for audio reproduction.

Additional features include tone controls for bass (+/- 7 dB) and treble (+/- 6 dB), as well as various filters for optimized sound output. The TA-F 808 ES employs high-quality construction elements such as a Gibraltar chassis and roof, along with gold-plated RCA jacks and brass speaker terminals, enhancing durability and audio quality. This amplifier series includes other models such as the TA-F 505 ES, TA-F 606 ES, and TA-F 707 ES, but the 808 ES stands out for its refined component placement and dual power supply.

TA-F 808 ES

The Sony TA-E 80 ES is a preamplifier manufactured between 1989 and 1996 in Japan. Designed in a sleek black or champagne finish, it offers both aesthetic appeal and high-quality performance. Weighing 12 kg, it features wooden side panels that contribute to its robust build. The unit has a power consumption of 20W and comes equipped with a remote control model RM-S 808 for convenience. It supports a variety of inputs including Phono MC with different impedances, Phono MM, Tuner, CD, Aux, and Tape, providing flexibility for system integration. The output connections include Tape Rec, Headphone, and both balanced and unbalanced outputs, ensuring compatibility with a range of devices. A notable technical specification includes a frequency response of 3Hz to 300kHz and a low distortion factor of 0.001%. The signal-to-noise ratio varies based on input type, with 105dB for line inputs. It offers tone control options for bass and treble adjustments at specific frequencies, enhancing the user’s listening experience. Additional features include loudness control, high and low filters, and a mute function.

TA-E 80 ES

The Sony TA-N 77 ES is a stereo power amplifier that was manufactured between 1987 and 1989 in Japan. It features a sleek black design and has remote control capabilities suitable for optimizing convenience in use. The amplifier consumes 510 watts of power and has dimensions of 470 mm in width, 185 mm in height, and 440 mm in depth, weighing 25 kg. It originally retailed for approximately 2,500 DM. The TA-N 77 ES supports multiple input types, specifically line-in fixed and line-in variable configurations, and can connect to two pairs of speakers. It offers impressive continuous power output, delivering 2x 200W at 8 Ohms, 2x 230W at 6 Ohms, and 2x 270W at 4 Ohms, with low total harmonic distortion ratings of 0.004% at a power level of 10W and 4 Ohms. The amplifier can also operate in BTL Mono mode, offering a substantial 1x 580W at 8 Ohms. Additional technical specifications include a frequency response of 1Hz to 200kHz (+0/-3dB) and a signal-to-noise ratio of 120dB. The TA-N 77 ES is equipped with two large VU meters for visual monitoring of output levels. It forms part of a series that includes other power amplifiers such as the Sony TA-N 55 ES and TA-N 80 ES, and pairs with preamplifiers like the Sony TA-E 77 ES and TA-E 77 ESD.

TA-N 77 ES

The Sony CDP-C77ES is a 5-disc carousel CD player with a digital filter and the company's unique Direct Bitstream Digital-to-Analog Conversion System. It was released in the early 1990s and is known for its high-quality audio performance.

CDP-C 77 ES

The Sony SEQ-333 ES is an equalizer produced during the late 1980s, likely between 1980 and 1989. It features a two-channel configuration with stereo L/R RCA inputs and outputs, making it a versatile choice for audio system integration. The device has both analog and digital audio features and offers an output power of 10 W. Its design is marked by a sleek black finish. The equalizer is aimed at achieving optimal audio tuning, allowing users to adjust frequency levels to their preference. This model’s quality and build indicate a focus on delivering satisfactory audio performance, catering to various listening environments and setups.

SEQ-333 ES

The Sony SEQ-711 is a graphic equalizer that was manufactured between 1992 and 1994 in Japan. It features a sleek black design and is equipped with a variety of capabilities aimed at enhancing audio quality. The unit has a power consumption of 13 watts and measures 430 mm in width, 110 mm in height, and 265 mm in depth, weighing approximately 3.2 kg. The SEQ-711 offers two inputs and one output, making it suitable for connections through tape, VCR, or MD loops. It is designed with a 7-band equalizer, providing a boost/cut range of ±10 dB, with center frequencies at 63 Hz, 160 Hz, 400 Hz, 1 kHz, 2.5 kHz, 6.3 kHz, and 16 kHz. The frequency response for line input ranges from 20 Hz to 50 kHz, with a distortion level lower than 0.01% and a signal-to-noise ratio greater than 100 dB. The graphic display includes a spectrum analyzer and features ten preset equalization curves for varying acoustic environments and listening preferences. Users can also define custom user equalization curves, which can be easily selected through dedicated keys. Special features include dynamic equalization control, a DSC (Dynamic Sound Control) function that adjusts equalization according to sound level, and option for tape/line input selections. The equalization presets support a range of acoustic simulations, from jazz clubs to modern cinemas and discotheques, enabling diverse sound experiences.

SEQ-711

The Sony PS-X 65 is a vintage turntable produced by Sony in the late 1970s to early 1980s. It features a linear tracking tonearm and a direct drive system. The turntable is known for its unique design and solid build quality.

PS-X 65

The Sony PS-6750 is a direct drive turntable that was manufactured in the 1980s. It is known for its high-quality construction and excellent sound reproduction.

PS-6750

Steve Dyer's setup is a harmonious blend of analog warmth and digital precision. Anchored by the Pro-Ject Carbon Debut turntable and driven by the stalwart Technics A900s MK2 power amplifier, his collection ensures each note resonates with clarity and depth. Surrounding these key pieces is a suite of audio classics, including the Technics cassette deck and CD player, the nostalgic Sony minidisc, and the crystal-clear tuner, all rounded off by the commanding Bowers & Wilkins speakers that deliver an immersive sound experience. This is where technology meets passion, creating a space that goes beyond listening to truly experiencing music.






The Audiophile's Eclectic Retreat

Technics A900s MK2

Technics RS-AZ6

Technics SL-PG590

Technics SR-GT360

Bowers and Wilkins series 500

Pro-Ject is a brand that specializes in manufacturing high-quality turntables and audio equipment.

Pro-Ject

The Pro-Ject Debut Carbon EVO is a high-quality turntable designed for vinyl enthusiasts seeking exceptional sound quality at a relatively affordable price point. The turntable features a specially regulated motor, a sturdy metal platter weighing nearly four pounds, and a carbon fiber tonearm, all engineered for optimal playback performance. One of its standout features is the ultra-high-precision chip that maintains perfect speed for the belt-driven deck, while a special thermoplastic elastomer ring on the platter helps reduce vibrations. Although it does not include an automatic return for the tonearm at the end of a record, these thoughtfully designed components contribute to an exceptionally clear and lively analog listening experience. The Debut Carbon EVO comes equipped with a Sumiko Ranier cartridge valued at approximately $150, and it includes a low-capacitance cable for connections. The turntable is available in various attractive finishes, such as navy blue, red, and wood-grain veneer, however, the classic nonreflective black option remains popular. Notably, the EVO lacks a built-in phono preamp, so users should verify that their amplifier includes one to properly process the turntable's output.

Debut Carbon EVO

Sony is a Japanese company that specializes in various electronics products, including HiFi audio equipment.

Sony

The Sony MDS-JE440 is a MiniDisc recorder/player that features a compact and efficient design, catering to the demands of both casual listeners and audio enthusiasts. It is capable of recording and playback of high-quality audio on MiniDisc media, a format that provides durability and convenience compared to traditional media options. The device supports features like editing functions, allowing users to create custom playlists and rearrange tracks with ease. It has a digital input for transferring audio directly from a variety of sources. The MDS-JE440 also incorporates a range of playback options, including shuffle and repeat functions, enhancing the listening experience. Its control panel is user-friendly, with a clear layout that makes navigation simple.
