The M 200 mono power amplifier embodies the highest standard of audiophile design, engineered to deliver uncompromising sound quality and powerful performance. By specializing in powering a single loudspeaker, the M 200 optimizes the audio experience, delivering purity and power that surpasses that of typical stereo amplifiers. With an impressive output of over 400 Watts, it mirrors the revered characteristics of the A 200 stereo amplifier, emphasizing precision, fine detail, and dynamic resolution.

Constructed with an unwavering attention to efficiency and sound distinction, the M 200 integrates advanced circuit topologies and exclusive technology, including the innovative HV and High-Frequency Sine-Wave mains section alongside the PURIFI Eigentakt™ power amplifier technology. These integrations ensure that the amplifier not only supports high power output but does so with remarkable sound fidelity and minimal distortion.

Distinctively, the M 200 showcases visually and functionally impressive heatsinks. These are crucial for optimal heat dissipation, particularly under high loads, ensuring consistent performance without overheating. The design acknowledges both aesthetic value and practical utility, highlighting the amplifier's inherent power.

Ideal as a stand-alone unit or as part of a more extensive audiophile setup, particularly with the Series 200, the M 200 power amplifier stands out as a robust component in any high-end audio system configuration. Its ability to adapt the damping factor accommodates speakers that benefit from a warmer or softer sound, proving its versatility and responsiveness to diverse audio needs. Through this, the M 200 not only contributes to but significantly enhances the overall quality and experience of specialized audio systems.

Features

Power Output:

  • 420 Watts @ 4 Ohms
  • 210 Watts @ 8 Ohms

Frequency Response:

  • +0 / -3 dB: 1 Hz – 60 kHz

Signal to Noise Ratio:

  • 113 dB

Total Harmonic Distortion (THD):

  • < 0.002%

Intermodulation Distortion:

  • < 0.002%

Damping Factor:

  • 800 / DF LO > 70

Gain Factor:

  • x 37 (31.4 dB)

Input Sensitivity:

  • High level (RCA): 1.13 Veff / 5.8 kOhms
  • Balanced (XLR): 2.26 Veff / 20 kOhms

Mains Power Requirements:

  • 220 – 240 V, 50 – 60 Hz

Power Consumption:

  • Max: 500 Watts
  • 25 Watts while power on and idling with no signal

Standby Power Consumption:

  • < 0.5 Watts

Dimensions:

  • Height × Width × Depth: 10 × 32 × 34 cm
  • 4 x 12.6 x 13.4 inches

Accessories Included:

  • Power cord
  • E2-Link cable

Weight:

  • 5 kg / 11 lbs

Finishes Available:

  • Alu silver anodized (43)
  • Alu schwarz anodized (42)
