Features
**Audio Formats Supported:**
- CD/DA, CD-R, CD-RW, CD Text
- MP3, WMA, AAC, OGG Vorbis, FLAC, WAV, AIFF, ALAC
**Data Rates:**
- PCM: 32 to 192 kHz, 16/24 Bit
- MP3: Up to 320 kBit, constant and variable Data rate
**Features:**
- Gapless Playback for MP3 (Lame), WAV, FLAC
- T+A MusicNavigator App for iOS and Android
**Standards:**
- UPnP AV
**Streaming Services Supported:**
- Tidal, Deezer, qobuz, Roon Ready (Subscription required)
**Interfaces:**
- LAN: Fast Ethernet 10/100 Base-T
- WLAN: 802.11 b/g/n
**Digital Inputs:**
- S/P-DIF: 2 high-quality co-ax and two optical TOS-Link; ranging from 32-192kSps, 16/24-bit
**USB Ports:**
- USB Device Mode: USB Class 2 mode; supports asynchronous data transferPCM mode, DSD mode (DSD 64 to DSD 512)
- USB Master Mode: 2 inputs (1×front panel, 1×back panel), supports streaming client formats
**Radio:**
- FM, FM-HD
- Frequency Range: 87.5 – 108 MHz (Europe/US Version), 76 – 90 MHz (Japan-Version)
- DAB, DAB+
- Frequency Range: 168 – 240 MHz (Band III)
**Bluetooth:**
- aptX® Bluetooth Audio transmission protocol A2DP (Audio), AVRCP 1.4 (Control)
**Outputs:**
- Analogue outputs high level (RCA): 2,2 Veff / 50 Ohms
- Analogue outputs balanced (XLR): 4,4 Veff / 50 Ohms
- Digital outputs: 1 × coax (IEC 60958 LPCM)
**Frequency Response and Dynamic Range:**
- 2 Hz – 20 kHz / 100 dB
- PCM / DSD frequency response varies by sample rate
- Total Harmonic Distortion: < 0.001 %
- Signal-to-Noise Ratio: 110 dB
- Channel Separation: 110 dB
**Up-Sampling:**
- Freely programmable signal processor with four selectable oversampling algorithms
**Additional Features:**
- Analogue filter: Phase-linear filter with automatic bandwidth switching
- Control interface: R2-Link
- Remote control: SRC 1, MusicNavigator App
**Power:**
- Mains Connection: 100 – 240 V, 50 – 60 Hz
- Maximum Power Consumption: 40 Watts
- ECO-Standby: 0.4 Watt
- Auto Power Off: Yes (after 90 minutes without audio signal)
**Optional Accessories:**
- Power Three HD (Carbon)
- Power Bar
- Audio Quad (Carbon)
- Audio Triax (Carbon)
- IP-Control
**Physical:**
- Dimensions (H x W x D): 8.2 × 46 × 40 cm
- Weight: 8 kg
- Finishes: Silver anodised aluminium (43), black anodised aluminium (42), brushed
