This high-fidelity haven showcases a McIntosh MC352 amplifier's sheer power coupled with the detailed clarity of B&W 803D3 speakers, presenting an audio experience that’s as pure as it is powerful. The turntable, the altar of this sacred listening space, spins vinyl with precision, honoring the collector's creed of authentic sound. Compact yet mighty, this setup isn’t just about listening; it's about reliving every note in a personal musical journey.

by: origalzur_vinyl_il


The Vinyl Enthusiast's Dream Setup

Rega PL 10

Tellurium Q silver diamond

The McIntosh MC352 is a powerful stereo amplifier delivering 350 watts per channel across different impedance loads (2, 4, or 8 ohms). This amplifier features a double-balanced push-pull design that employs matched amplifiers for superior performance, significantly reducing distortion to an impressive 0.005% at rated power output. Additionally, the MC352 incorporates McIntosh's exclusive output autoformers, allowing it to effectively match the output impedance to various loudspeakers without compromising audio quality. The amplifier supports both unbalanced and balanced inputs and boasts a signal-to-noise ratio of 85dB (unbalanced) and 115dB (balanced), ensuring clear audio reproduction. With a frequency response of 20Hz to 20kHz, it offers minimal variation (+0 / -0.25dB) across its operational range. Constructed with robust materials, it weighs around 110 lbs (approximately 50 kg), making it a substantial addition to any audio setup. The MC352 also includes power protection features such as Power Guard, which prevents clipping distortion, and Sentry Monitor, which safeguards the amplifier from excessive current. Its design incorporates the iconic McIntosh blue meters, adding a distinctive visual element that appeals to both aesthetics and functionality.

MC352

The B&W 803 D4 is a high-performance floor-standing speaker that brings advanced design and technological innovation to a more compact form factor than its larger siblings, the 801 D4 and 802 D4. Part of the prestigious 800 Series Diamond lineup from Bowers & Wilkins, the 803 D4 features a three-box construction, incorporating a dedicated midrange enclosure known as the Turbine Head. This design isolates the 130mm (5-inch) midrange cone to enhance clarity and sound reproduction. The Reverse Wrap cabinet is constructed from a single continuous curve of wood, which improves sound dispersion while reducing cabinet resonance. Enhanced Matrix™ bracing reinforces the internal structure, further minimizing unwanted vibrations and ensuring a well-defined soundstage. The speaker is equipped with two Aerofoil™ bass cones housed in solid aluminum bass pods, optimizing the mechanical location for powerful bass performance while mitigating distortion. The 803 D4 utilizes advanced materials such as the Continuum cone and Biomimetic Suspension, ensuring superior midrange transparency. With a frequency range of 16Hz to 35kHz, a sensitivity of 90dB, and a nominal impedance of 8Ω, the 803 D4 is capable of delivering a dynamic and immersive listening experience. The speaker's elegant finishes, available in gloss black, satin walnut, satin rosenut, and white, combined with leather trim, blend aesthetics and acoustic performance seamlessly.

803 D4

This setup is a cozy corner for anyone who loves the warm crackle of a vinyl record and the rich sounds of jazz. It's a mix of old and new, with pieces like the Sansui 9090 receiver and Luxman MQ60 tube amplifier bringing out the best in classic records. These pieces are known for making music feel full and alive, which is perfect for getting lost in the grooves of a good jazz album. The turntable, a Denon DP-57L with its special Denon 103D pickup, is ready to spin any record, from the newest pressings to old favorites, making sure every note is clear and vibrant.

The setup also has a nod to the days of mixtapes with a Technics cassette deck, ready for when you feel like a retro vibe. And when it's time for something more modern, there's a Pioneer CD player that keeps digital tunes sounding great. Everything comes together through Klipsch speakers that make sure every song fills the room without missing a beat. It's a space that's built for sinking into the music, whether that's a lively jazz tune or any song that means something special.

by: jazz_and_vinyl


The Warmth of Vinyl and Jazz

The Sansui 9090 and 990 are vintage receivers that were produced in the 1970s, recognized for their robust build quality and exceptional audio performance. Both models are part of the Sansui's 90 series, featuring significant power amplification through their impressive output stages. The Sansui 9090 has an output power of 120 Watts per channel, while the 990 model boasts an even more powerful 130 Watts per channel. These receivers include multiple inputs for connecting various audio sources, such as turntables, tape decks, and CD players. They often feature tuning dials with analog displays, offering a classic aesthetic alongside high-quality sound reproduction. The units typically incorporate a range of sound adjustment controls, including bass, treble, and balance. In terms of connection options, both models generally feature speaker terminals allowing for various speaker configurations, making them versatile in different audio setups. Additionally, their FM and AM radio capabilities include a sensitive tuner for better reception and sound clarity.

9090/990

The Luxman MQ-60 is a vacuum tube power amplifier that exemplifies the craftsmanship and engineering excellence associated with Luxman products. This amplifier is designed to drive a variety of speakers while delivering a warm, rich sound signature typical of tube amplification. The MQ-60 employs 6L6GC output tubes and is configured in a push-pull design, allowing it to achieve both high fidelity and dynamic range. It features a robust power supply section that ensures stable operation even under load. The amplifier produces a power output of approximately 30 watts per channel, which is adequate for driving medium to high efficiency speakers. Its frequency response typically ranges from 20 Hz to 20 kHz, maintaining a solid performance across the audible spectrum. The MQ-60 is praised for its intricate design, which includes a beautifully laid-out chassis and high-quality components, reflecting the brand's commitment to audio excellence. The amplifier comes with various input options, allowing for versatile connectivity. Overall, the Luxman MQ-60 is highly regarded for its sound quality, aesthetic appeal, and reliable performance.

MQ-60

The Technics RS-630 USD is a cassette deck introduced by Technics.

RS-630 USD

The Denon DP-57L is a direct-drive turntable that features a sleek and stylish design, reflecting the aesthetics of the late 1970s and early 1980s. It is engineered for optimal playback performance and aims to reproduce audio with authenticity and clarity. The turntable is equipped with a high-torque direct-drive motor, which ensures consistent speed and stability. The unique construction of the DP-57L includes a heavy, damped chassis that helps minimize vibrations and unwanted resonance during playback. This model also features an S-shaped tonearm, designed to reduce tracking error and optimize record contact. Additionally, it has an adjustable tracking force and anti-skate control to further enhance playback accuracy. The DP-57L is compatible with a range of cartridges, allowing users to customize their audio experience based on personal preferences. The unit's build quality is robust, aimed at durability and longevity, making it a solid choice for vinyl enthusiasts.

DP-57 L

The Denon DL-103 D is a moving coil (MC) phono cartridge made by Denon. It is known for its exceptional sound quality and has been highly regarded by audiophiles and enthusiasts. The DL-103 D features a low output voltage and requires a phono preamp or step-up transformer with sufficient gain. It has a diamond stylus for accurate tracking and a rugged construction for durability. The DL-103 D is designed to be used with a high-quality turntable setup and is often considered a benchmark in the world of audiophile cartridges.

DL-103 D

The Pioneer PD-S 701 is a compact disc player manufactured by Pioneer from 1992 to 1993 in Japan. It features a sleek design available in black and champagne colors. The player is equipped with remote control functionality and has a power consumption of 16 watts. Its dimensions are 420 mm in width, 276 mm in height, and 130 mm in depth, with a weight of 4.2 kg. The PD-S 701 offers both variable and fixed audio outputs. It utilizes a 1-bit transducer and provides an impressive frequency response range from 2 Hz to 2 kHz, with a dynamic range exceeding 96 dB and a signal-to-noise ratio greater than 108 dB. The distortion factor is minimal at less than 0.0026%. While it does not support CD-Text, MP3 playback, or pitch control, it includes features such as auto play, shuffle, title programming, and repeat modes. The player is compatible with CD-R, CD-RW, and HDCD formats.

PD-S 701

The PHO-701 is an enhanced version of the successful PHO-700 tube phono preamplifier, offering significant improvements in customization and sound quality. Unlike its predecessor, the PHO-701 includes DIP-switches, allowing users to make precise adjustments tailored to their specific pick-up cartridge needs. This feature eliminates the need for compromises typically required in many other phono preamplifiers. Consequently, users experience a notable enhancement in sound quality and fine resolution, achieving a richer and more detailed audio reproduction.

PHO-701

The Klipsch Forte III is a floor-standing loudspeaker that continues the legacy of the Forte series with modern enhancements aimed at delivering superior audio performance. The speaker features a 12-inch woofer, a 6.5-inch midrange driver, and a 1-inch titanium compression driver coupled with a Tractrix horn for high frequencies. The combination of these drivers produces a seamless and dynamic sound across a broad range of frequencies. The Forte III offers a sensitivity rating of approximately 99 dB, allowing it to produce high sound pressure levels with relatively low input power. It also features a frequency response that ranges from 38 Hz to 20 kHz, providing deep bass and crisp treble sound. The crossover network is designed to ensure smooth transitions between the drivers, and the cabinet is constructed from high-quality wood veneers, enhancing both aesthetics and acoustics. The speakers are compatible with different amplifier types, making them versatile for various audio setups. Along with these acoustic features, the Forte III benefits from a solid build quality, ensuring durability and longevity. It is also equipped with dual binding posts, allowing for bi-wiring or bi-amping configurations, enhancing its performance capabilities. Overall, the Forte III maintains Klipsch's commitment to high-efficiency sound reproduction, making it a compelling choice for audiophiles and music enthusiasts alike.

Forte III

Exploring the nuances of high-fidelity sound, one encounters the Stax SR-X9000, an impressive manifestation of electrostatic headphone technology known for its impeccable audio reproduction. The detail and clarity that these headphones provide allow for a deep dive into the layers of one’s favorite tracks, revealing subtle elements that typically remain hidden with conventional audio equipment. It's an auditory journey through the landscape of sound, where each frequency is presented with striking definition.

Paired with the SR-X9000 is the IFI audio Pro IESL, a capable energizer that ensures these sophisticated headphones are powered to deliver their full sonic potential. It’s an essential piece of the high-fidelity puzzle, facilitating the delivery of clean and consistent audio. In alliance with the Pro IESL, the Stax SRM-717 amplifier serves as the backbone of this setup. Known for its stability and precision, the SRM-717 underscores the experience by offering a steady hand to guide the electrostatic performance to its fullest expression, ensuring that every listening session is as rich and engaging as a live performance.

by: an_2a3






Nuances of Electrostatic Headphones

IFI audio Pro IESL

Stax is a Japanese brand known for producing high-quality electrostatic headphones and earphones.

Stax

The Stax SRM-717 is a solid-state headphone amplifier designed specifically for electrostatic headphones. It is engineered to deliver high-quality audio reproduction with exceptional speed and clarity. Featuring a fully DC-coupled signal path, the SRM-717 eliminates the use of capacitors in audio pathways, resulting in a more direct and transparent sound. The architecture is built primarily on a current domain amplification design, which facilitates a rapid response and extended frequency range. The amplifier's first stage functions as a voltage-controlled current sink, with a subsequent stage transitioning to a current-controlled voltage source, culminating in a constant current sink in the last stage. This design approach reduces the Miller Effect, thus enhancing high-frequency performance. With a low output impedance of approximately 25 ohms, it is well-suited to drive electrostatic headphones, and it achieves a total harmonic distortion of under 0.02%. The amplifier can handle voltages up to 800 volts peak-to-peak, allowing for loud output levels suitable for electrostatic models like the Omega series. With its compact and robust build, the SRM-717 is appreciated for its reliability and sound fidelity, making it a compelling choice for serious audio enthusiasts looking to drive advanced headphone technology.

SRM-717

The Stax SR-X9000 is a flagship electrostatic earspeaker that incorporates advanced technologies for an unparalleled listening experience. It features the newly developed MLER-3 (Multi-Layer Electrodes) fixed electrode technology, which consists of a four-layer design combining mesh and conventional etching electrodes. This allows for a rigid structure that significantly reduces resonance and enhances sound transmission characteristics compared to traditional designs. The diaphragm utilizes ultra-thin engineering film, which is 20% larger than that of the previous model, SR-009S, providing a lightning-fast reaction speed and a broad frequency response. The SR-X9000 boasts a frequency response range of 5 - 42,000Hz and an impedance of 145kΩ, with a sound pressure sensitivity of 100dB, operating on a bias voltage of 580V DC. Its construction features a tough machined aluminum enclosure to eliminate unnecessary vibrations and enhance acoustic clarity. Additionally, the guard mesh is uniquely designed to control reflections, ensuring smoother sound wave flow. The earspeaker is equipped with genuine leather ear pads, improving comfort and sound isolation, while its stainless steel arc assembly enhances durability and fit. Included are ultra-pure annealed copper and silver-plated cables, available in two lengths, and it is packaged in a wooden case made from paulownia wood for optimal storage.

Nuances of Electrostatic Headphones
