610LP

**Power Supply Features:** - Independent Inductive DC Filtering (i2DCf) - One inductor per IC in signal path (24 stages total) **Impedance Loading:** - 64 settings from 12.1Ω to 47kΩ **Capacitance Loading:** - 16 settings from 0pF to 1120pF **Gain Level Settings:** - 16 settings from 40dB to 70dB **Equalization Curves:** - Selectable for RIAA and IEC standards **External Power Supply Compatibility:** - Fully compatible with 820S external power supply **Specialized Components:** - Metallized polypropylene film capacitors with 1% tolerances **Inputs:** - XLR: 1 pair - RCA: 1 pair **Signal-to-Noise Ratio (S/N):** - 112dBr at full scale @ 40dB gain - 93dBr at full scale @ 70dB gain **IEC Curve Effect:** - -7dB at 10Hz **Frequency Response:** - 20Hz - 20kHz ±0.1dB **Crosstalk:** - -106dB at 1kHz **Output Impedance:** - 50Ω **Total Harmonic Distortion (THD):** - 0.001% (20Hz - 20kHz) **Intermodulation Distortion:** - 0.002% **Input Overload:** - @40dB gain: 200V RMS (XLR), 100V RMS (RCA) - @70dB gain: 5mV RMS (XLR), 2.5mV RMS (RCA) **Physical Specifications:** - Shipping weight: 40 lb / 18 kg - Dimensions (W x H x D): 18.75 x 4.0 x 16.8 in / 47.6 x 10.2 x 42.7 cm
