PA 2000 R

### General Features - **Frequency Response**: +0 / -3 dB: 0.5 Hz – 300 kHz - **Signal-to-Noise Ratio**: Unweighted/A-weighted: 105/109 dB - **Total Harmonic Distortion/Intermodulation**: < 0.001% / < 0.001% - **Channel Separation**: > 90 dB - **Loudness**: Switchable, variable to suit loudspeaker efficiency ### Tone Controls - **Bass/Treble**: Switchable, channel-separate; Range: -6 … +8 dB ### Input Sensitivity & Impedance - **High Level (RCA)**: 3 × 250 mV … 4 Veff/20 kOhms - **Balanced (XLR)**: 3 × 500 mV … 8 Veff/5 kOhms - **Optional Phono-MM**: 1 - 5 mV, 16 Capacitances - **Optional Phono-MC**: 60 – 1000 µV, 16 Impedances ### Headphone Output - **Impedance**: 50 Ohms ### Outputs - **PRE Out RCA**: Nom 1 Veff, Max 9.5 Veff, 75 Ohms - **Nominal Output per Channel**: - into 8 Ohms: 100 Watts - into 4 Ohms: 200 Watts - into 2 Ohms: 300 Watts ### Additional Technical Characteristics - **Slew Rate**: 60 V/µs - **Damping Factor**: > 65 - **Total Harmonic Distortion**: < 0.02% - **Reservoir Capacity**: 60000 µF - **Control Interface**: R2-Link - **Remote Control**: SRC 1 - **Mains Connection**: 100 – 120 V or 200 – 240 V, 50 – 60 Hz, Max. 1000 Watts - **Standby Power Consumption**: < 0.5 W - **Trigger Input**: +5V … 20V via adapter plug for remote power-on - **Surround Pass Through**: Input 3 (symmetric) or 5 (asymmetric) can be configured ### Optional Accessories - **Phono Modules**: PHE-P/PA R MM or MC - **Other Accessories**: Power Three HD (Carbon), Power Bar, Audio Quad (Carbon), Speaker Hex (Carbon) ### Physical Specifications - **Dimensions**: 8.2 × 46 × 40 cm (H x W x D) - **Weight**: 10.5 kg - **Finishes**: Silver anodised aluminium (43), black anodised aluminium (42), brushed
