Sanyo is a Japanese electronics company that produces a wide range of products including audio equipment like HiFi systems.

Sanyo

The Sanyo TP-20 is a semi-automatic turntable produced by Sanyo from 1979 to 1982, made in Japan. It features a sleek anthracite color and has dimensions of 440 mm in width, 140 mm in height, and 360 mm in depth, weighing approximately 4.5 kg. The TP-20 utilizes a belt drive system powered by a DC servo motor, allowing it to operate at two speeds: 33 1/3 RPM and 45 RPM, with synchronous speed fine adjustment capable of maintaining stability within < 0.1%. The rumble noise level is rated at greater than 60 dB, ensuring minimal background noise during playback. The turntable platter measures 292 mm in diameter and weighs 0.4 kg, contributing to its overall performance. The tonearm is S-shaped, statically balanced, with an effective length of 220 mm and an overhang of 15 mm. Additionally, it supports a contact pressure range of 0.5 to 3 grams and has a cartridge weight capacity of 4 to 10 grams. The unit is equipped with hardwired line-out connections via Cinch for outputting audio. The TP-20 was priced around 350 DM in 1980 and forms part of a broader series of Sanyo audio products.

TP-20

by Sanyo

Request Price
